RTM1

快速霍尔测量仪器

参数分析仪-SMU

参数分析仪-CVU

参数分析仪-PMU

Measure capability

DC, AC, pulsed I-V, van-der-Pauw,  零漂移霍尔测量，

DC I-V

DC I-V

AC C-V

Pulsed I-V

Measure ranges

±20 V

±0.1 A

10 GΩ

DC – 20 kHz

±10 V

±0.1 A

100 kΩ

DC

±210 V

±1 A

10 TΩ

DC

±1 VAC

±0.001 A

1 kHz – 10 MHz

DC precision

0.2 µV

100 pA

10 µΩ

1mV

1μA

10mΩ

0.2 µV

0.1 pA

N/A

N/A

AC precision

0.1 nV

1 nA

10 nΩ

0.2 ps phase

1 pF, 10 nH

N/A

N/A

0.3 ps phase

0.001 pF

N/A

Drift

<0.1 ppm/K

No spec

No spec

No spec

No spec

Pulses

±40 V

±0.1 A

10 µs

No measurement

N/A

N/A

N/A

±40 V pulse

±0.8 A

20 ns

200 MS/s measure

Switch Unit

Integrated

4x8 Matrix switch

Switch mainframe with matrix card

N/A

N/A

N/A
